Electromagnetic fail-safe brakes are spring applied and use an electromagnetic solenoid to hold the brake open. If the brake is turned off or power is lost, the spring engages the brake.

We incorporate both electromagnetic disc and drum brakes into our industrial braking systems. We also provide comprehensive repair services for these brakes.

Advantages:

Electromagnetic brakes allow for quick operation, as they set more quickly than most other types of fail-safe brakes. They also allow for adjustable torque, which enables fine tuning of the braking process. Electromagnetic brakes are often used when environmental contamination by leaking fluids is a major concern (e.g., hydraulic fluid in the case of hydraulic brakes).

Disadvantages:

Electromagnetic brakes are generally more expensive than other types of fail-safe brakes (e.g., a pneumatic brake that achieves a comparable torque level). This is because electromagnetic brakes are inherently expensive due to the amount of expensive materials like copper they require. Similarly, electromagnetic brakes can be difficult to fit into small spaces, especially when compared to hydraulic brakes. Finally, electromagnetic brakes may not be the best option if the application requires a high duty cycle, a situation in which electrohydraulic thruster brakes excel.

Products

93 results

Filter

Name

Type

Actuation

Maximum Torque (N·m)

Diameter (mm)

View as:
93 results
  • electromagnetic disc brake, industrial disc brake, fail-safe disc brake, 5E
    5E – 220

    Type: Disc
    Maximum Torque: 155 N·m
    Diameter: 220 mm

  • electromagnetic disc brake, industrial disc brake, fail-safe disc brake, 5E
    5E – 200

    Type: Disc
    Maximum Torque: 150 N·m
    Diameter: 200 mm

  • 65E, Electromagnetic fail-safe disc brake. Spring applied electromagnetically released.
    65E – 175

    Type: Disc
    Maximum Torque: 145 N·m
    Diameter: 175 mm

  • industrial electromagnetic drum brake, fail-safe drum brake, Antec LAM brake
    LAM 8″

    Type: Drum
    Maximum Torque: 140 N·m
    Diameter: 203.2 mm

  • 66E, Electromagnetic disc brake, spring applied electromagnetically released
    66E – 355

    Type: Disc
    Maximum Torque: 135 N·m
    Diameter: 355 mm

  • 66E, Electromagnetic disc brake, spring applied electromagnetically released
    66E – 315

    Type: Disc
    Maximum Torque: 115 N·m
    Diameter: 315 mm

  • 66E, Electromagnetic disc brake, spring applied electromagnetically released
    66E – 260

    Type: Disc
    Maximum Torque: 85 N·m
    Diameter: 260 mm

  • 66E, Electromagnetic disc brake, spring applied electromagnetically released
    66E – 220

    Type: Disc
    Maximum Torque: 75 N·m
    Diameter: 220 mm

  • 66E, Electromagnetic disc brake, spring applied electromagnetically released
    66E – 175

    Type: Disc
    Maximum Torque: 65 N·m
    Diameter: 175 mm
